IMAC

The Thermobile IMAC, is our most powerful mobile air heater with a capacity of up to 380kW. Built on a sturdy galvanised frame with stainless steel panels which makes the IMAC both robust and easy to transport. Designed to provide air heating to large spaces. Our IMAC line burns both diesel and alternative fuels such as HVO and GTL.

Need advice? Call +31 (0)7 65 87 34 50  or send a message

Diesel
Petroleum/Kerosine
HVO
GTL
Optional: Propane Gas
Optional: Natural Gas

IMAC

Compare Performances

Heat calculator

Calculate how much kW is needed for a specific room.

Length (m)

Width (m)

Height (m)

Desired indoor temperature (°C)

Outdoor temperature (°C)

K-value (W/m³·K)

Ventilation (Air changes per hour)

Air flow (m³/u)

Output (KW)

Calculated heat demand *

Characteristics

Automatic burner control with thermostat connection.

High-efficiency heat exchanger ( approx. 92% ).

Blow-out temperature with a delta ΔT of about 47°C.

The EC fan is equipped with a soft starter.

Equipped with overheating protection and temperature limiter.

2T: Equipped with two-stage burner.

Equipped with intercal industrial burner with flow control. Alternative burners available (Riello oil or gas burner e.g.).

Economical thanks to recirculation connection option.

Easily movable via forklift slots and lifting eyes and stackable.

Fitted with phase-following relay as standard.

Fleet Manager possible.

Applications
Documents

Heating of storage sheds, workspaces, halls.
Drying and heating new construction and renovation projects.
Ventilate temporary shelters, tents (summer mode).
Drying of agricultural products.

40020927__07__MANUAL__IMAC__2000S__LR 40019006__01__MANUAL__IMAC__2000__2200__3000__EC__2T 40.020.949_v05-2011_IMAC4000 (eur)40022080__07 IMAC 2000 S 40022090__06 IMAC 4000 40022094 REV02 IMAC 2000 EC 40022099 REV04 IMAC 2200 EC-2T 40022102__03 IMAC 1200 - 1500 RDD 40022149_02 IMAC 3000 EC 2T

Heating of storage sheds, workspaces, halls.
Drying and heating new construction and renovation projects.
Ventilate temporary shelters, tents (summer mode).
Drying of agricultural products.

Frequently Asked Questions

The temperature of the intake air is cooled back by about 12°C. It is therefore important to always recirculate the air from the room to be cooled. (In this case, the air is drawn in from the room and blown back into the room with a temperature approximately 12°C lower).

This depends on the area and volume, insulation of the building and application. A rule of thumb is 40W per m3 for insulated buildings and 60W per m3 for tents, for example.

For all heaters with an oil-fired auxiliary burner, the burner can be replaced with a gas-fired auxiliary burner.
